APC BV1000I-MSX Ghana



APC BV1000I-MSX Ghana

The APC BV1000I-MSX Ghana provides power protection for unstable power conditions, ensuring consistent and reliable connectivity at the most critical moments. Featuring a battery backup and surge protector for Electronics and Computers

Category:

Description

APC BV1000I-MSX UPS Ghana

The APC BV1000I-MSX Ghana provides power protection for unstable power conditions, ensuring consistent and reliable connectivity at the most critical moments. Featuring a battery backup and surge protector for Electronics and Computers, APC BV1000I-MSX is trusted to protect critical data and equipment from power problems by supplying clean and reliable network-grade power. APC BV1000I-MSX Ghana automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment. Besides, it preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.

APC BV1000I-MSX Ghana is an intelligent system providing an easy-to-read status of the unit and utility power conditions, issuing notification of changing utility power and UPS power conditions. Such crucial alerts include, battery failure notification whereby early-warning fault analysis on batteries allows timely preventive maintenance. Also, maximizes battery performance, life, and reliability through intelligent, precision charging. APC BV1000I-MSX is easy to install, allowing flexibility for setup in tight locations and mounting on wall or other surfaces.

Key Features

  • Output power capacity : 600Watts /1.0kVA
  • Output Connections : (6) IEC 320 C13 (Battery Backup)
  • Nominal Output Voltage : 230V
  • Nominal Input Voltage : 230V
  • Input Connections : IEC-320 C14
  • Cord Length : 1.52meters

Safety-agency approved
APC BV1000I-MSX Ghana has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Sleek design
It is slim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home decor.

Boost Automatic Voltage Regulation (AVR)
Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.

Cold-start capable
APC BV1000I-MSX Ghana provides temporary battery power when the utility power is out.

Transformer-block spaced outlets
Protect equipment with input transformer blocks without blocking access to other receptacles.

LED Indicators
Provide easy-to-read status of the unit and utility power conditions.

Audible alarms
Provides notification of changing utility power and UPS power conditions

Battery and surge-protected outlets
Back up and protect your hardware and data during power outages, surges, and spikes.

Battery backup and surge protection
Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage

Intelligent battery management
APC BV1000I-MSX Ghana packs intelligent management that maximizes battery performance, life, and reliability through intelligent, precision charging.

Advanced Safety Features
Safeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations.

Battery failure notification
Get early-warning fault analysis on batteries enabling timely preventive maintenance

Technical Specifications

Output

  • Max Configurable Power (Watts) : 600 Watts / 1.0kVA
  • Output Frequency (sync to mains) : 50/60 Hz +/- 1 Hz Unsynchronized
  • Topology : Line-interactive
  • Waveform type : Stepped approximation to a sinewave
  • Transfer Time : 6 ms typical: 10 ms maximum

Input

  • Frequency : 50/60 Hz +/- 5 Hz Auto-sensing
  • Input voltage range for main operations : 170 – 280V
  • Number of Power Cords : 1

Batteries & Runtime

  • Battery type : Lead-acid battery
  • Expected Battery Life (years) : 3 – 5

Physical Data

  • Height : 93MM, 9.25CM
  • Width : 161MM, 16.05CM
  • Depth : 305MM, 30.5CM
  • Net Weight : 5.7KG
  • Shipping weight : 6.0KG
  • Height : 237MM, 23.7CM
  • Width : 143MM, 14.3CM
  • Depth : 373MM, 37.3CM
  • Color : Black
  • SCC Codes : 10731304344053

Datasheet Download
