Ruijie RG-EG2100Pv2 Router Ghana features a EasyGate (EG) Next-generation Unified Security Gateway that is a multi-functional Cloud Managed designed for various industries.

Description

Ruijie RG-EG2100Pv2 Unified Security Gateway Ghana

Ruijie RG-EG2100Pv2 Router Ghana features a EasyGate (EG) Next-generation Unified Security Gateway that is a multi-functional Cloud Managed designed for various industries. Equipped with high-performance multi-core MIPS hardware architecture, the Ruijie RG-EG2100Pv2 Router Ghana supports a wide range of features such as high-performance NAT, WAN load balancing, smart flow control, online behavior management, visualized IPsec VPN, web authentication, etc. Taking advantage of integrated Hard Disk Drive (HDD), the EG Security Gateway can provide local storage for Internet activities logging, which is essential for National Internet Security Compliance in many countries.

The Ruijie RG-EG2100Pv2 Next-generation Unified Security Gateway is also supported by Ruijie Cloud, altogether with switches and wireless access points, Ruijie Cloud can provide a comprehensive secure networking platform for centralized management allowing for device monitoring, configuration as well as firmware management. For ease of provisioning, Ruijie provide an innovative Mobile App Dummy Provisioning for SME customers. In less than 3-min, user can complete the Gateway initial setup with Internet connectivity, without any PC setup or cable installation.

Features

  • Smart Flow Control & AAA Integration
  • User Online Behavior Management
  • VPN & Traffic Visualization
  • FREE Cloud Management
  • App Caching for Download Acceleration
  • Built-in Internet Audit Log Storage (EG3250)
  • Built-in Power-Over-Ethernet Integration (EG-2100-P v2)
  • Mobile App Dummy Provisioning (EG-2100-P v2)

Smart Flow Control & AAA Integration

  • Smart P2P speed limit, accurate identification of P2P software, and automatic transmission of uplink source quench message to control the downlink traffic and prevent downlink bandwidth exhaustion.
  • Support over 120 popular application in DPI engine and enjoys FREE for life signature update Role-based flow control based on usernames and user groups to facilitate the allocation of bandwidths according to different departments.
  • Support AAA (Authentication, Authorization and Accounting) with web authentication, integration with AAA Software and simple traffic accounting feature

Online Behavior Management

Ruijie RG-EG2100Pv2 Router Ghana Unified provides detailed online behavior management of the intranet users, blocking a variety of non-work-related websites to create a good working atmosphere and improve work efficiency.

VPN Visualization

Ruijie SME Security Gateway has significantly simplified the VPN configuration, which could be completed just by a few clicks, eliminating the need for professional maintenance. The Ruijie RG-EG2100Pv2 Ghana enables users to view and control the traffic in the VPN tunnel, establishing a visualized VPN to guarantee the security of key services using VPN.

Traffic Analysis

Equipped with powerful DPI technology, the Ruijie RG-EG2100Pv2 Ghana collects traffic usage statistics based on users, applications and links for report generation, providing reliable historical data for bandwidth expansion as well as user and application-based bandwidth control policies.

Centralized Cloud Management

Couple with Ruijie Cloud services, the Ruijie RG-EG2100Pv2 Router Ghana monitored & managed from the centralized cloud services. Ruijie Cloud is the free cloud-based management platform for all the Security Gateway series. No hardware or servers required to be installed on customer premise. Device monitoring, configuration changes & firmware management can be performed easily in anytime, anywhere & anyway.

Online Behavior Management

Ruijie EG Next-generation Unified Security Gateway provides detailed online behavior management of the intranet users, blocking a variety of non-work-related websites to create a good working atmosphere and improve work efficiency.

VPN Visualization

Ruijie RG-EG2100Pv2 Ghana has significantly simplified the VPN configuration, which could be completed just by a few clicks, eliminating the need for professional maintenance. The gateway enables users to view and control the traffic in the VPN tunnel, establishing a visualized VPN to guarantee the security of key services using VPN.

Traffic Analysis

Equipped with powerful DPI technology, the Ruijie RG-EG2100Pv2 Ghana collects traffic usage statistics based on users, applications and links for report generation, providing reliable historical data for bandwidth expansion as well as user and application-based bandwidth control policies.

Centralized Cloud Management

Couple with Ruijie Cloud services, the Ruijie EG Security Gateway is now able to be monitored & managed from the centralized cloud services. Ruijie Cloud is the free cloud-based management platform for all the Security Gateway series. No hardware or servers required to be installed on customer premise. Device monitoring, configuration changes & firmware management can be performed easily in anytime, anywhere & anyway.

Built-in Power-Over-Ethernet (POE)

Designed for retail, small organizations and distributed enterprises with remote and branch offices, the Ruijie RG-EG2100Pv2 Router Ghana integrate support for PoE devices. It come with 7 POE Out ports to provide power to and endpoint like, video cameras, security access control (card scanners), point-of-sales devices, IP phones, wireless access point and many more. It eliminates the complexity of providing extra power cabling especially the small organization or retail wireless network deployment.

Specifications

Model RG-EG2100-P v2 RG-EG3250
Hardware Specification
CPU Multi-core MIPS
Fixed Ports 8 1000BASE-T ports (7x POE/POE+)
  • 8 1000BASE-T ports
  • 1 SFP port
  • 1 SFP+ port (non-combo)
WAN Ports Upto 2 Upto 6
Flash 4GB EMMC 8M SPIFLASH
Hard Disk N/A Standard 1TB
Memory 512M 2G
Performance & Feature
Performance 1000Mbps (1518 bytes) 6000Mbps (1518 bytes)
450Mbps (512bytes) 3725Mbps (512bytes)
70Mbps (64 bytes) 800Mbps (64 bytes)
Concurrent Session 100,000 600,000
Recommended Concurrent User 300 2000
App Caching Support Support
Cache Capacity 750MB 100GB
Cache Resources Android APK & Apple IOS Android APK & Apple IOS; Windows System Patches
Network Protocol
  • Support TCP/IP protocols, including IP, ICMP, IGMP, TCP, UDP, etc.
  • Support multiple routing protocols, including static routing, RIP (V1 / V2) and OSPF
  • Support DHCP Relay and DHCP Server
  • Support PPPoE Client
  • Support NAT and multiple NAT ALG including FTP, H.323, DNS, etc.
  • Support ARP, trusted ARP, proxy ARP, etc.
  • Support Ping and Traceroute fault detection
Application Visibility
  • Support self-developed 43 types of applications / more than 120 application features, customizable protocol identification:
  • P2P : BitTorrent, eMule, Thunder, EDONKEY, FlashGet & etc.
  • Multimedia : YouTube, Facebook Video, WebEx Conference & etc.
  • Social Media : Facebook, Twitter, LinkedIn, Pinterest & etc.
  • VOIP/Chat : Skype, Viber, Google Hangout, Jabber, Facebook Messenger & etc.
  • Instant Messaging/Email : Gmail, MSN, QQ, YAHOO & etc.
  • Software Update : Window, McAfee, Kaspersky, ESET & etc.
  • Cloud-based File Collaboration : GoogleDrive, Dropbox, OneDrive, iCloud & etc.
  • Enterprise Application :HTTP, FTP, SMTP, POP3, IMAP, Telnet, LOTUS-NOTES, SQL Server, Oracle, Mysql, HTTPS & etc.
URL Filtering
  • Support custom URLs
  • Support remote HTTP automatic URL library upgrade
  • Local log storage (NAT log, traffic log, URL log, etc.)
  • Support storage on external log server
WAN Load Balancing Support (upto 2 WAN Port) Support (upto 6 WAN Port)
IPsec VPN Tunnel 16 1000
Network Security
  • Anti-ARP Spoofing
  • Defense against malicious attacks from internal and external networks
  • Support secure address binding
  • Block WAN Ping
  • Prevent Port Scan Attack
  • Prevent Fragmentation Attack
  • Prevent ICMP Flood Attack
  • Prevent Teardrop Attack
  • Prevent Ping of Death Attack
  • Prevent Land Attack
  • Prevent Smurf / Fraggle attack
  • Prevent SYN Flood Attack
Ruijie Cloud Integration Feature
  • Support device health monitoring status
  • Support centralized configuration change management & backup
  • Support Top 10 Application/User traffic visualization
  • Support device firmware management
  • Support event-based alarm notification
Other Features Integrate with AAA software to support multiple authentication modes
Other Features

Service and Support

Support push advertising page
Support multi-link load balancing
Support remote HTTP online upgrade for signature library, software version, etc.
Lifetime Free signature library upgrade
Rack Height 1U 1U
Weight 2KG 4kg
Power Supply 100-240V~,50-60Hz,3A 100-240V~,50-60Hz,0.65A
PoE Budget 135W NA
Power Consumption <150W <25W
Dimensions (W x D x H) (mm) 200×200×43.6 440×200×43.6
Operating Temperature 0°C to 45°C 0°C to 40°C
Operating Humidity 10% to 90%RH 10% to 90%RH
