Ruijie RG-AP710 Accesspoint Ghana



Ruijie RG-AP710 Access Point Ghana

The Ruijie RG-AP710 Accesspoint Ghana is a cost effective 802.11ac access point with 2×2 MIMO and concurrent Dual-band design, data rate of upto 1.167Gbps. This Access Point boasts of Ruijie hybrid management flexibility

Description

Ruijie RG-AP710 Access Point Ghana

The Ruijie RG-AP710 Accesspoint Ghana is a cost effective 802.11ac access point with 2×2 MIMO and concurrent Dual-band design, data rate of upto 1.167Gbps. This Access Point boasts of Ruijie hybrid management flexibility, allowing its users to choose the Ruijie Cloud Management and Hardware Controller for varies fast-changing business needs. Despite the availability of cloud or hardware-based controller, all integrated with advanced radio optimization, wireless roaming as well as secure authentication out-of-box. The entry AP710 with balanced performance perfect for small to medium office, retail chains and budget hotel for their indoor scenarios.

Ruijie Rg Ap710 Accesspoint Ghana

Ruijie Rg Ap710 Accesspoint Ghana

Features

  • Maximize ROI (Lifetime Free Cloud Management & WIS Optimization Service).
  • Hybrid Management (Cloud / Controller / Standalone).
  • Fast Provisioning by Ruijie Cloud Mobile APP.
  • Automated Radio Optimization by Big Data Technology.
  • Stylish Design (Integrated Antenna).
  • Indoor 802.11ac Access Point,
  • dual-radio,
  • dual-band,
  • 2 spatial streams,
  • access rate up to 1.167Gbps,
  • 1 10/100/1000BASE-T uplink port;
  • Bundled with Ruijie Cloud Service lifetime license (PoE and local power adapters sold separately).
Ruijie Rg Ap710 Accesspoint Kumasi

Ruijie Rg Ap710 Accesspoint Kumasi

High Performance
With 802.11ac Concurrent Dual-Band design, the AP710 data rate is up to 1.167Gbps, sufficient for majority small office and retail store environment. Plus 100% Cloud Management and 3-Year Warranty, the entry AP710 provides the perfect balanced of price performance for small-medium business users.

Migration from 11n to 11ac
The Ruijie RG-AP710 Accesspoint Ghana adopts 802.11ac standard with data rate up to 1.167Gbps, providing 2.5 times faster experience than previous generation of 802.11n.

Hidden Cabling Design
The Ruijie RG-AP710 Accesspoint Ghana employs a simplistic and stylish design to fit different scenarios.

Flexible Hybrid Management
The Ruijie RG-AP710 Accesspoint Ghana has 3 different management modes for selection, perfect for your ever changing business needs

Standalone
Featuring a compact device Ruijie RG-AP710 Accesspoint Ghana is Simple to install only with basic connectivity

Cloud Management
Easy & Effective Choice without Provisioning

Hardware Controller
Ruijie RG-AP710 Accesspoint Ghana is a high Performance with 3rd Party Integration

Hassle-free Authentication
With PPSK Enterprise Authentication AP710 provides new experience feature to manage wireless password for staffs in secure and simple way

Zero Provisioning
It only has 4-Step Fast Provisioning by Ruijie Cloud Mobile APP

Ruijie Rg Ap710 Accesspoint Accra

Ruijie Rg Ap710 Accesspoint Accra

Specifications

Model Ruijie RG-AP710
Target Deployment Retail Chain Store, Small & Medium-sized Business Office, Boutique Hotel
Type Indoor Ceiling/Wall-mounting
Basic Specifications Radio Concurrent Dual-band
Protocol 802.11a/b/g/n/ac
Operating Bands
  • 802.11b/g/n : 2.4GHz to 2.483GHz
  • 802.11a/n/ac : 5.150GHz to 5.350GHz, 5.47GHz to 5.725GHz, 5.725GHz to 5.850GHz (vary depending on countries)
Antenna Built-in Omni-directional Antenna
Antenna Gain 2.4G: 3dBi

5G: 3dBi

Max Throughput
  • Maximum throughput of 2.4G : 300Mbps
  • Maximum throughput of 5G : 867Mbps
  • Maximum throughput per AP : 1167Mbps
Modulation
  • OFDM :BPSK@6/9Mbps,QPSK@12/18Mbps,16-QAM@24Mbps,64-QAM@48/54Mbps
  • DSSS :DBPSK@1Mbps,DQPSK@2Mbps,and [email protected]/11Mbps
  • MIMO-OFDM :BPSK, QPSK, 16QAM, 64QAM, 256QAM
Receiver Sensitivity
  • 11b :-96dBm(1Mbps),-93dBm(5Mbps),-89dBm(11Mbps)
  • 11a/g :-91dBm(6Mbps),-85dBm(24Mbps),-80dBm(36Mbps),-74dBm(54Mbps)
  • 11n :-90dBm(MCS0),-70dBm(MCS7),-89dBm(MCS8),-68dBm(MCS15)
  • 11ac HT20 :-88dBm(MCS0), -63dBm(MCS9)
  • 11ac HT40 :-85dBm(MCS0), -60dBm(MCS9)
  • 11ac HT80 :-82dBm(MCS0), -57dBm(MCS9)
Spatial Streams 2×2
Maximum Transmit Power 100mW
IP Rating IP41
Ports
  • 1 10/100/1000BASE-T Ethernet uplink
  • Port LAN1 supports PoE
  • 1 Console Port
Power Power Supply
  • local power supply (DC 5V/3A)
  • PoE (802.3af)
Power Consumption <12.95W
WLAN Maximum clients per AP 256
BSSID capacity 32
Remote Intelligent Perception Technology (RIPT) Support
Intelligent load balancing based on the number of users or traffic Support
STA control Support
Bandwidth control Support
Preference for 5GHz (band select) Support
Band Steering (5G Priority) Support
Security PSK, Web, 802.1x authentication Support
PPSK authentication Support
Data encryption WPA (TKIP), WPA2 (AES), WPA-PSK, and WEP (64 or 128 bits)
PEAP authentication Support
User isolation Support
Rogue AP detection and countermeasure Support
RADIUS Support
Wireless Intrusion Detection System(WIDS) Support
Wireless Intrusion Prevention System (WIPS) Support
Routing IPv4 address Static IP address or DHCP reservation
IPv6 address Manual or automatic configuration
Multicast Multicast to unicast conversion
Management and Maintenance Network management SNMP v1/v2C/v3, Telnet, TFTP, Web management
Cloud AC management Support
FAT/FIT switching Support
External Characteristics Lock Support
LED Indicators 1 LED indicator (red, green, blue, orange, and flashing modes, breathing flashing mode for smart device access, and the indicator can be switched off to enable silence mode)
Relevant Standard Wi-Fi Alliance Certification Support
Radio Standard
  • EN300 328
  • EN301 893
EMC Standard
  • GB9254
  • EN301 489-1
  • EN301 489-17
  • EN 55032
  • EN 61000
  • EN 55035
Safety Standard
  • GB4943
  • EN/IEC 60950-1
Specifications Dimensions (W x D x H) (mm) 194 × 194 × 37
Weight 0.42kg
Work Environment Temperature
  • Operating Temperature : -10°C to 50°C
  • Storage Temperature : -40°C to 70°C
Humidity
  • Operating Humidity : 5% to 95% (non-condensing)
  • Storage Temperature : 5% to 95% (non-condensing)
