Qnap TS-879U-RP Ghana



Qnap TS-879U-RP Ghana

The Qnap TS-879U-RP Ghana features 8 Bay IP-SAN Storage Solution with 10GbE Bundle. Serving as IP-SAN (iSCSI) and NAS, deployable in different business and enterprise applications as backup center, disaster recovery, file sharing, virtualization and video editing storage

Description

Qnap TS-879U-RP Ghana

The Qnap TS-879U-RP Ghana features 8 Bay IP-SAN Storage Solution with 10GbE Bundle. The high performance server is both IP-SAN (iSCSI) and NAS, easily deployable in different business and enterprise applications such as backup center, disaster recovery, file sharing, virtualization and video editing storage. The Qnap TS-879U-RP Ghana offers a variety of security options to prevent unauthorized access to your data, even in the event that the hard drive or device is stolen. Sophisticated RAID configurations and hot-swap capabilities are present that offer high performance, protection and minimized rebuilding time. The dual OS embedded on the DOM architecture offers extra assurance that the system will boot up.

Qnap TS-879U-RP features an Intel Core i3 Processor, 2 GB DDR3 memory, 10 Gigabit network capability and a 6 GBps SATA interface for high performance and fast data transfer rates. It also provides fast data backup via USB 3.0. Qnap TS-879U-RP is easy to set up locally or through remote access as it does not require IT skills. Easy management tools like instant SMS or Email alert, the hard drive S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) feature and system resource monitor are integrated to keep administrators up-to-date on their NAS at all times.

Key Features

Simple Management
The TS-879U-RP features the easy-to-use QTS 4.0 operating system and provides a user-friendly web GUI that allows administrators to easily manage the NAS so there is no need for an extensive knowledge of complex commands. Simple management tools such as instant SMS/Email alert, the hard drive S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) feature and system resource monitor are provided to keep administrators up-to-date on their NAS at all times.
Secure Your Data
Data might seem insecure being open in a network, but the Qnap TS-879U-RP offers a variety of security options such as encrypted access, IP filtering, policy-based automatic IP blocking and more. In addition, full control of the NAS is offered down to the user and folder access rights to determine who can access the NAS and what can or cannot be accessed. The TS-879U-RP is packed with security features to stop all unauthorized data access such as AES-256 volume-based encryption. The AES-256 volume-based encryption prevents sensitive data from unauthorized access and data-breach even if the hard drives or the device is stolen.
Scalable
As your business grows, so will your data. TS-879U-RP supports online capacity expansion by cascading multiple Qnap RAID expansion enclosures. With the Qnap scale-up solution, hundreds of Terabyte raw capacity is supported and it is especially useful for large data applications, such as video surveillance, data archiving and TV broadcast storage.
Simply connect Qnap RAID expansion enclosures to the TS-879U-RP and power it on. TS-879U-RP will detect the hard drives in the RAID expansion enclosures as newly installed local drives. The storage capacity of the TS-879U-RP can be expanded seamlessly by using the powerful QTS Storage Manager.
 Reliable
The TS-879U-RP is reliable with built-in safety precautions to safeguard all data from any unforeseen problems. With multiple built-in features to promise no interruptions to the work flow of a business, the TS-879U-RP is an efficient asset. The advanced RAID configurations and hot-swap capabilities are included to give RAID performance, protection and reduced rebuilding time. Moreover, the dual OS embedded on the DOM architecture ensures the system will boot up. If one of the two operating systems fails, the healthy operating system will boot up and operate normally while repairing the failed operating system. The dual Gigabit LAN ports can also be configured for failover which allows the NAS server to sustain the failure of one network port and still provide continuous services.
High Performance
The TS-879U-RP features Intel Core i3 Processor, 4GB DDR3 memory, 10 Gigabit network capability and 6Gb/s SATA. Even the most demanding requirements in data center or corporate networks can be satisfied by the TS-879U-RP. With outstanding data transfer rate of over 1,000 MB/s data throughput and 100,000 IOPS 1, intensive business applications and concurrent tasks can be easily fulfilled.
SSD cache acceleration
The Qnap TS-879U-RP supports SSD caching which can greatly boost IOPS performance of storage volumes. It is perfect for improving overall workflow of IOPS demanding applications such as virtualization.
NAS + iSCSI/IP-SAN Solution for Server Virtualization

With increasing virtualization of IT resources, the need for high performance storage is more essential than ever. The TS-879U-RP offers class-leading system architecture matched with 10 GbE networking performance designed to meet the needs of demanding server virtualization, such as VMware, Citrix and Windows Hyper-V. 10 GbE network speeds greatly increase the agility of data transmission in a virtualized environment intensifying NFS and iSCSI connection performance.
Run multiple OS’
The Virtualization Station transforms the TS-879U-RP into a 2-in-a-box NAS that can function as an All-in-One NAS and a virtualization platform supporting multiple operating systems, fast virtual machine creation, virtual machine import/export, snapshot and enables desktop operations on web browser. With the easy-to-use interface, you can centrally manage all virtual machines created on the TS-879U-RP with least efforts. Furthermore, you can download VMs on demand from the online VM markets and import them to TS-879U-RP to use directly without any complex procedure.
High Network Bandwidth

The Qnap TS-879U-RP offers network expansion options which includes dual-port 1 GbE and dual-port 10 GbE network expansion cards, to aggregate and boost network performance. The TS-879U-RP includes two Gigabit (GbE) LAN ports which can be expanded to four GbE LAN ports or two 10 GbE LAN ports plus two GbE ports.
Blazing Fast Data Backup via USB 3.0
The TS-879U-RP features USB 3.0 ports for high speed backup to external hard drives. ExT3, ExT4, NTFS and HFS+ file systems are supported to ensure compatibility with Windows, Mac OS x and Linux operating systems.

Convenient Central storage

The Qnap TS-879U-RP Ghana users can use the same login name and password to access. Conveniently connecting to the shared folders of other servers on Microsoft Networking through the “portal folder” on the TS-879U-RP reducing the hassle of logging in to different servers one by one. The TS-879U-RP supports mounting ISO images of CD and DVD discs for network sharing folders for data archiving, storage and sharing. This feature saves space from storing the physical discs, reduces the risk of data loss caused by long term use of the discs and enhances the performance of data sharing on a business network. A central repository of log data from various network devices allows efficient management and security auditing in businesses. Qnap Syslog server allows the IT administrator to effectively collect and store logs of other network devices in the Turbo NAS

Cross-platform Sharing
The TS-879U-RP supports SMB/CIFS, NFS and AFP protocols for file sharing across Windows, Mac, Linux/UNIX networks. User accounts and shared folders can be created via the user-friendly web-based interface without IT expertise. The integrated antivirus solution for the Turbo NAS ensures business continuity by offering detection against the latest viruses, malware, worms and Trojan horses

Backup Center for Business
The TS-879U-RP offers a complete backup solution for businesses with Qnap QBack/NetBak Replicator which supports real-time and scheduled data backup from Windows PCs, Apple Time Machine backup from Mac OS and third party backup software such as Acronis True Image and Symantec Backup Exec.
Disaster Recovery Solution
Real-time Remote Replication (RTRR) provides real-time or scheduled data replication between the TS-879U-RP and a remote Qnap NAS, an FTP server or an external drive. The Turbo NAS has taken iSCSI LUN backup/restore to a whole new level with snapshot technology. The IT administrator can use the LUN snapshot to back up contents in the LUN to various storage destinations, including Windows shared folders via SMB/CIFS, Linux shared folders via NFS or local shared folders on the Turbo NAS. Qnap is ready to send private data to the clouds! The TS-879U-RP supports Amazon S3, ElephantDrive and Symform cloud backup storage which have several backup modes including real-time, scheduled backup and versioning control so that the data can be restored from any point of time. Cloud storage can be monitored through a web browser. An extra set of all of the data stored will always be available, so remote data recovery is quick and simple.
iSCSI and Virtualization Deployment
The TS-879U-RP is fully VMware and Citrix ready and Windows Hyper-V compliant. The TS-879U-RP can serve as a NAS for file sharing and iSCSI storage concurrently. The TS-879U-RP supports multiple LUNs (Logical Unit Numbers) and iSCSI targets. LUNs can be flexibly mapped to, unmapped from and switched among different iSCSI targets. Designed with CHAP authentication and LUN masking, the advanced ACL (Access Control List) offers the capability to block unauthorized access from the initiators. Compared with a high cost Fibre Channel SAN, the TS-879U-RP is an affordable system that can be deployed as a storage center for virtualized and clustered server environments, such as VMware and Microsoft Windows Failover Cluster.

Qnap TS-879U-RP Specifications

CPU Dual Core Intel® Core™ i3-3220 Processor 3.3 GHz
Memory System memory: 4 GB DDR3 RAM
Memory module pre-installed: 4 GB x1
Total memory slots: 4
Memory expandable up to: 32 GB (8GB x4)
Flash Memory 512MB DOM
Hard Drive 8 x 3.5” or 2.5” SATA 6Gb/s, SATA 3Gb/s hard drive or SSD
NOTE:The standard system is shipped without hard drives.
Hard Drive Tray 8 x hot-swappable and lockable tray
LAN Port 4 x Gigabit RJ-45 Ethernet port (Optional dual-port 10 Gb and 1 Gb network card are supported)
LED Indicators Status, 10 GbE, LAN, eSATA, hard drives
USB 2x USB 3.2 Gen 1 port (rear)
4x USB 2.0 port (rear)
eSATA 2 (rear)
Buttons System: Power button and reset button
LCD Panel Mono-LCD display with backlight,
Enter button, Select button for configuration
Alarm Buzzer System warning
Form Factor 2U, Rackmount
Dimensions 88(H) x 439(W) x 520(D) mm
3.46(H) x 17.28(W) x 20.47(D) inch
Weight Net weight: 12.52 kg/27.61 lb
Gross weight: 20.76 kg/45.78 lb
Sound Level (dB) Standby: 54.57 dB
In operation: 54.6 dB
(with 8 x 1TB hard drives installed)
Power Consumption (W) Sleep mode: 68W
In Operation: 130W
(with 8 x 1TB hard drives installed)
Temperature 0~40˚C
Relative Humidity 5~95% RH non-condensing, wet bulb: 27˚C.
Power Supply Input: 100-240V AC, 47-63Hz
Output: 300W
Expansion Slot 2 (for network and storage expansion)
VGA Reserved for system maintenance
Fan 3 x 6 cm smart cooling fan



Datasheet Download
