Cisco SG550XG-24F Ghana



Cisco SG550XG-24F Ghana

The Cisco SG550XG-24F Ghana features the next-generation stackable managed Ethernet switch, designed to provide advanced capabilities and superior performance you need to support a more demanding network environment at an affordable price.

Category:

Description

Cisco SG550XG-24F Network Switch Ghana

The Cisco SG550XG-24F Ghana features the next-generation stackable managed Ethernet switch, designed to provide advanced capabilities and superior performance you need to support a more demanding network environment at an affordable price. Cisco SG550XG-24F Ghana switch incorporates fan and power hardware redundancy, increasing overall network availability. At the same time, Cisco SG550XG-24F Ghana switch is easy to deploy and manage, without a large IT staff. Cisco SG550XG-24F Ghana is designed to protect your technology investment as your business grows. Unlike switches that claim to be stackable but have elements that are administered and troubleshot separately, the Cisco 550X Series provides true stacking capability, allowing you to configure, manage, and troubleshoot multiple physical switches as a single device and more easily expand your network. A true stack delivers a unified data and control plane, in addition to a management plane, providing flexibility, scalability, and ease of use because the stack of units operates as a single entity constituting all the ports of the stack members. Cisco SG550XG-24F Ghana Switch provides the advanced feature set that growing businesses require and that high-bandwidth applications and technologies demand.

Features

Advanced features for demanding environments

Get 10 Gigabit Ethernet and advanced capabilities to accelerate your business growth. Featuring next-generation stackable managed switch Cisco SG550XG-24F Ghana, can bring immediate productivity gains to your organization. The switch also provides your network ready for more bandwidth-hungry applications in the future.

Affordable 10 Gigabit Ethernet

10 Gigabit Ethernet delivers 10 times the performance to your network to promote higher productivity and business efficiency. The Cisco SG550XG-24F Ghana breaks the barrier of 10 Gigabit Ethernet adoptions with exceptional affordability.

Superior reliability and resiliency

Keep your network running so your business never slows down. The Cisco SG550XG-24F Ghana offers true stacking, built-in fan redundancy, a redundant power supply connector, and high-availability protocols.

Advanced features

The Cisco SG550XG-24F Ghana includes capabilities and management options you need to support applications today and in the future, such as strong security, advanced QoS, comprehensive IPv6 support, and Layer 3 dynamic routing.

Power over Ethernet

The Power over Ethernet Plus (PoE+) standard provides up to 30 watts of power per port. The Cisco SG550XG-24F Ghana also support 60W PoE on selected ports to power compact switches and high-power wireless access points.

Energy efficiency

Cisco SG550XG-24F Ghana packs a variety of energy-saving features, including energy-detect mode, cable-length detection, and Energy-Efficient Ethernet, provide an eco-friendly and cost-effective network solution without compromising performance.

Specifications

Cable
Connectivity Details Type Serial cable
Included Qty 1
Capacity
Type VLANs supported
Value 4094
Type IPv4 routes (static)
Value 8000
Type IPv6 routes (static)
Value 4000
Type ACL rules
Value 2000
Type QoS hardware queues
Type 8
Dimensions & Weight
Depth 13.8 in
Height 1.7 in
Weight 9.17 lbs
Width 17.3 in
Environmental Parameters
Humidity Range Operating 10 – 90% (non-condensing)
Humidity Range Storage 10 – 90% (non-condensing)
Max Operating Temperature 122 °F
Max Storage Temperature 158 °F
Min Operating Temperature 32 °F
Min Storage Temperature -4 °F
Flash Memory
Installed Size 256 MB
Header
Brand Cisco
Compatibility PC
Product Line Cisco Small Business
Interface Provided
Connector Type RJ-45
Type
  • (2) 10GBase-T
  • (24) SFP+ 10GBase-X
  • Type A USB
Miscellaneous
Authentication Method RADIUS , Secure Shell (SSH) , TACACS+
Color Category Black
Compliant Standards CSA 22.2 , FCC Part 15 A , UL 60950
Encryption Algorithm MD5 , SSL
MTBF 642,449.21 hours
Networking
Advanced Switching Layer 3
Compliant Standards IEEE 802.1ab (LLDP) , IEEE 802.1D , IEEE 802.1p , IEEE 802.1Q , IEEE 802.1s , IEEE 802.1w , IEEE 802.1x , IEEE 802.3 , IEEE 802.3ab , IEEE 802.3ad (LACP) , IEEE 802.3az , IEEE 802.3u , IEEE 802.3x , IEEE 802.3z
Connectivity Technology Wired
Features 16MB packet buffer , 802.1x authentication , Access Control List (ACL) support , ARP support , BOOTP support , Bridge protocol data unit (BPDU) , Broadcast Storm Control , Denial of Service (DoS) , DHCP client , DHCP relay , DHCP server , DHCP snooping , DHCP support , DiffServ Code Point (DSCP) support , DiffServ support , DoS attack prevention , Dynamic ARP Inspection (DAI) , Energy Efficient Ethernet , Flow control , Generic Attribute Registration Protocol (GARP) , Generic VLAN Registration Protocol (GVRP) , IGMP snooping , Internet Control Message Protocol (ICMP) , IP source guard , IP-MAC binding , Link Aggregation Control Protocol (LACP) , LLDP support , Management Information Base (MIB) , Multicast Storm Control , Multicast VLAN Registration (MVR) , Multiple Spanning Tree Protocol (MSTP) support , Port Security , Quality of Service (QoS) , Rapid Spanning Tree Protocol (RSTP) support , Spanning Tree Protocol (STP) support , STP Root Guard , Syslog support , Type of Service (ToS) , Uni-Directional Link Detection (UDLD) , Unicast Storm Control , Virtual Route Redundancy Protocol (VRRP) support , Weighted Round Robin (WRR) queuing
Form Factor Desktop , Rack-mountable
Jumbo Frame Support 9000 bytes
MAC Address Table Size 64K entries
Manageable Yes
Max Units In A Stack 8
Ports Qty 24
Power Over Ethernet (PoE) No
Remote Management Protocol CLI , HTTP , HTTPS , RMON , SCP , SNMP 1 , SNMP 2c , SNMP 3 , SSH , TFTP
Routing Protocol CIDR , IGMP , IGMPv2 , IGMPv3 , MLD , MLDv2 , RIP , Static IPv4 routing , Static IPv6 routing , VRRP
Stackable Stackable
Status Indicators Fan , Link/activity , Port transmission speed , RPS (Redundant Power Supply) , System
Subcategory Network hubs and switches
Subtype 10 Gigabit Ethernet
Type Switch
Power Device
Features Redundant Power System (RPS) connector
Frequency Required 50/60 Hz
Nominal Voltage AC 120/230 V
Power Consumption Operational 77.5 Watt
Type Internal power supply
RAM Size 512 MB
