Grandstream ghp610w Ghana



grandstream ghp610w ghana

The grandstream ghp610w ghana IP Phone integrates dual-band Wi-Fi support providing 3-way voice conferencing making it ideal for hotel deployments as well as many other similar environments

Category:

Description

Grandstream ghp610w hotel ip phone ghana

The grandstream ghp610w ghana IP Phone integrates dual-band Wi-Fi support providing 3-way voice conferencing making it ideal for hotel deployments as well as many other similar environments. It supports full-band OPUS voice codec and features an advanced jitter-resilience algorithm that tolerates up to 30% packet loss without impacting voice quality. The grandstream ghp610w ghana is a compact IP phone that provides an HD speaker on the handset, 2 SIP accounts/lines, 10 speed dial keys and 3 programmable keys. Part of the GHP Series of Hotel Phones, these simple IP phones are also ideal for hospitals, apartments, dormitories, retail and more. The grandstream ghp610w ghana is supported by Grandstream’s Device Management System (GDMS), which provides a centralized interface to configure, provision, manage and monitor deployments of Grandstream endpoints. Thanks to a compact design that can be easily used on a desktop or wall-mounted, grandstream ghp610w ghana is ideal for hotel deployments as well as many other similar environments.

Features

  • 2 SIP Accounts, 2 Lines
  • GDMS online device management and provisioning
  • 3-way audio conferencing for easy conference calls
  • Integrated dual-band 2.4GHz & 5GHz 802.11 a/b/g/n/ac (GHP610W & GHP611W only)
  • Includes one 100Mbps network port with PoE (GHP610 & GHP611 only)
  • Speed dial label and swappable faceplate to allow for easy customization
  • Hearing Aid Compatibility (HAC)
  • Enterprise-level protection including secure boot, dual firmware images, and encrypted data storage

Specifications

 Protocols/Standards

  • SIP : SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, TLS, SRTP Network : IPv4, IPv6, HTTP/HTTPS, ARP, ICMP, DNS(A record, SRV, NAPTR), DHCP, SSH, TFTP, NTP, STUN, LLDP, TR-069, 802.1x

Network Interfaces

  • One auto-negotiation 10/100 Mbps ethernet port integrated PoE Class 2 (GHP610/GHP611)

Wi-Fi

  • GHP610W/GHP611W integrated dual-band 2.4GHz & 5GHz 802.11 a/b/g/n/ac

Feature Keys

  • 23 keys, including 3 programmable keys, 12 Standard Phone Digits keys (0-9 : speed dial keys configuration on web page, *, #), 5 Function keys (Flash, Redial, Hands-free, Voice Mail, Hold), 3 Volume Control keys, Up/Down/Mute (with red color LED)

HD Audio

  • One HD handset support for wide band audio

Voice Conferencing

  • 2 SIP accounts and lines, up to 3-way conference

Voice Codecs and Capabilities

  • Support for G.729A/B, G.711µ/a-law, G.726, G.722 (wide-band), G.723, iLBC, and full band OPUS. In- band and out-of-band DTMF (in audio, RFC2833, SIP INFO), VAD, AEC, CNG, PLC, AGC, AJB.

Telephony Features

  • Dial, Answer, Transfer, Conference, Redial, Flash, Hands-free, Voice Mail (with the server) Hold / Unhold, Mute /Unmute, flexible dial plan, Speed dial server redundancy & fail-over Call out.

Advanced Features

  • Support for multicast paging and E911 service
  • Support for advanced jitter-resilience algorithm
  • Supports GDS Door Opening

Wall Installation

  • 1 Wall Mountable Base

QoS

  • Layer 2 QoS (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS

Security

  • Secure boot, random default password, unique security certificate per device, administrator level passwords, 256-bit AES encrypted configuration file, SRTP, TLS, 802.1x media access control

Multi-language

  • English and Chinese

Upgrade/Provisioning

  • Firmware upgrade via FTP/TFTP / HTTP / HTTPS, fast boot in 15 seconds, mass provisioning using GDMS/TR-069 or AES encrypted XML configuration file

Power & Green Energy Efficiency

  • Universal power adapter (GHP610W/GHP611W) : Input : 100~240Vac 50~60Hz Output : 12V/0.5A(6W)

Temperature and Humidity

  • Operation : 0°C to 40°C
  • Storage : -10°C to 60°C
  • Humidity : 10% to 90%
  • (Non-condensing)

Package Content

  • GHP61X phone, handset with cord, base, universal power supply (GHP610W & GHP611W), Quick Installation Guide

Color

  • White (GHP610 & GHP610W), Black (GHP611 & GHP611W)

Physical

  • 211mm(L)*53mm(W)*44mm(H) (with handset) Unit weight : 300g (GHP610/GHP611), 350g (GHP610W/GHP611W US), 360g (GHP610W/GHP611W World) Package weight : 445g (GHP610/GHP611), 515g (GHP610W/GHP611W US), 525g (GHP610W/GHP611W World)

GHP610 & GHP611 Compliance

  • FCC : Part 15 Subpart B, Class B; Part 68. 316/317. CE : EN 55032; EN 55035; EN IEC 61000-3-2; EN 61000-3-3; EN IEC 62368-1. UKCA : BS EN 55032; BS EN 55035; BS EN IEC 61000-3-2; BS EN 61000-3-3; BS EN 62368-1. RCM : AS/NZS CISPR32; AS/NZS 62368.1; AS/CA S004, AS/CA S040. IC : ICES-003; CS-03 Part V.

GHP610W & GHP611W Compliance

  • FCC : Part 15 Subpart B, Class B; Part 15 Subpart C,15.247; Part 15 Subpart E,15.407; Part 68. 316/317. CE : EN 55032; EN 55035; EN IEC 61000-3-2; EN 61000-3-3; EN IEC 62368-1; ETSI EN 301489-1\- 17; ETSI EN 300 328; ETSI EN 301 893; EN 50360; EN 50566; EN 50663; EN 62209-1; EN 62209-2; EN 62479; EN IEC 62311. UKCA : BS EN 55032; BS EN 55035; BS EN IEC 61000-3-2; BS EN 61000-3-3; BS EN 62368-1; ETSI EN 301489-1\-17; ETSI EN 300 328; ETSI EN 301 893; BS EN 50360; BS EN 50566; BS EN 50663; BS EN 62209-1; BS EN 62209-2; BS EN 62479; BS EN IEC 62311. RCM : AS/NZS CISPR32; AS/NZS 4268; AS/NZS 2772.2; AS/NZS 62368.1; AS/CA S004; AS/CA S040. IC : RSS-247; RSS-Gen; RSS-102; ICES-003; CS-03 Part V.

Datasheet Download
